Description
Mechanical Data | |
Number of Cells | 144Cells(6×24) |
Dimensions of Module L*W*H(mm) | 2279×1134×35mm |
Weight(kg) | 31kg |
Glass | Double-sided glass 2mm |
Frame | anodized aluminum alloy |
J-BOX | IP68,3 diodes |
Cable | 4.0mm² 300mm or customized |
Wind/Snow Load | 2400Pa/5400Pa* |
Connector | MC Compatible |
Maximum power two-sided ratio | 70±5% |
*For more details please check the installation manual |
Temperature Ratings | |
Nominal Operating Cell Temperature(NOCT) | 42±2℃ |
Temperature Coefficient of Isc | +0.045%/℃ |
Temperature Coefficient of Voc | -0.25%/℃ |
Temperature Coefficient of Pmax | -0.3%/℃ |
Maximum Ratings | |
Operational Temperature | -40 – +85℃ |
Maximum System Voltage | 1500V DC |
Max Series Fuse Rating | 25A |
Packaging Configuration | |
Module per box | 31+31=62pieces |
Module per 40’container | 620pieces(35Frame) |
