With a green light wavelength of 532nm, the absorption rate of highly reflective materials such as copper and aluminum is increased to over 40%, the processing efficiency is 3 to 5 times higher than that of traditional infrared lasers, and the heat-affected zone is reduced by 90%! 1-30ns, peak power reaching the hundred-kilowatt level, easily achieving micron-level precision cutting, welding and micro-processing. All-solid-state/fiber optic design, 24-hour continuous operation without failure, power fluctuation less than 3%, and lifespan over 100,000 hours.
| Product Parameter | Data |
| Wave length： | 532 nm |
| Average power： | 48 W at 40 kHz 40 W at 200 kHz |
| Pulse energy： | ~65 ns at 40 kHz ~250 ns at 200 kHz |
| Pulse width(nominal)： | Single shot to 200 kHz |
| Pulse stability 2： | < 1.5% rms |
| Average power stability3： | ±2% rms |
| Light spot mode： | TEMO0 M2 < 1.2 |
| Spot pointing stability： | < 25 yrad |
| Spot divergence Angle： | ~2 mrad |
| Spot roundness： | ~90% |
| The diameter of the light spot at the light outlet4： | ~1 mm |
| Polarization ratio： | Vertical; 100:1 |
