Description
| Product Attribute | |
| Battery type | Lithium-ion battery |
| Grid connection | Off-grid, hybrid grid |
| Size (L * W * H) | 1400*1400*2200mm |
| Weight | 2200kg |
| Communication port | rs485, Can shape, Ethernet |
| Class of protection | IP65 |
| Cooling | Air cooling |
| Application program | Liquid cooled outdoor energy storage system |
| Rated charge and discharge performance | 0.5C/1C |
| Nominal voltage [V] | 768-1331.2 |
| Rated battery capacity [Ah] | 280 |
| Rated network frequency [Hz] | 50/60 |
| Power factor | > 0.99 |
| Dc component | <0.5% In |
| Inlet protection | IP54 |
| Communication | CAN, RS485 |
